Hikvision HWN-2108H-8P HiWatch Network Video Recorder

H.265+/H.265/H.264+/H.264 video compression Up to 60 Mbps incoming bandwidth, and 60 Mbps outgoing bandwidth Up to 8-ch network camera inputs Up to 4-ch 1080p decoding capability HDMI and VGA simultaneous output Model HWN-2104H-4P HWN-2108H-8P Video Input IP Video Input 4-ch 8-ch Up to 4 MP resolution Network Incoming bandwith 40 Mbps 60 Mbps Outgoing bandwith 60 Mbps Video Output Recording resolution 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF HDMI/VGA output resolution 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz Decoding Decoding format H.265+/H.265/ H.264+/H.264 Live view/Playback resolution 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF Synchronous playback 4-ch 8-ch Capability 1-ch @ 4 MP / 2-ch @ 1080p Hard Disk SATA 1 SATA interface Capacity Up to 6TB capacity for each disk Network Management Network protocols TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP External Interface Network interface 1 RJ-45 10/100Mbps self-adaptive Ethernet interface USB interface 2 × USB 2.0 PoE Interface Interface 4, RJ-45 10/100 Mbps self-adaptive Ethernet interface 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface Power = 36W = 75W Standard IEEE 802.3 af/at General Power supply 48 VDC Power = 50W = 90W Consumption (without hard disk and PoE) = 10 W Working temperature -10 to +55º C Working humidity 10 % to 90 % Chassis 1U chassis Dimensions 200 × 205 × 48 mm 285 × 215 × 48 mm Weight (without hard disk) = 1 kg
